Spesifikasi IKA MINISTAR 20 digital Overhead Stirrers

Cari berbagai macam dari pilihan terlengkap Alat Laboratorium Umum.

IKA MINISTAR 20 digital Overhead Stirrers

Description Product

The space-saving high performers from IKA MICROSTAR and MINISTAR series have been complemented by additional models. The new and easy-to-use stirrers convince with perfect basic functionalities, as well as with a compact design.

Compact design
The reduced design and the focus on the most essential aspects make the new IKA MICROSTAR and MINISTAR stirrers reliable laboratory companions.

Constant torque
All models of the IKA MICROSTAR and MINISTAR series guarantee a constant torque over the entire rpm range. The new devices are available in six different versions with rpms of up to 2,000 rpm and a torque of up to 80 Ncm.

Ease of operation
Operation takes place using a stable rotary knob. The display clearly shows the rotational speed.

Rapid updates
Regular software updates can be undertaken rapidly and simply via the USB interface.

Scope of delivery

MINISTAR 20 digital
R 300 shaft protector
Fasten screws for R 300 (2 pcs.)
chuck key

Technical Data

Stirring quantity max. per stirring position (H2O)	15 l
Motor rating input	60 W
Motor rating output	46 W
Motor principle	Brushless DC
Speed display	LED
Speed range	0/50 - 2000 rpm
Viscosity max.	10000 mPas
Output max. at stirring shaft	42 W
Permissible ON time	100 %
Torque max. at stirring shaft	20 Ncm
Speed adjustment	Turning knob
Setting accuracy speed	±1 rpm
Deviation of speed measurement n > 300rpm	±1 %
Deviation of speed measurement n < 300rpm	±3 rpm
Stirring element fastening	chuck
Chuck range diameter	0.5 - 8.2 mm
Hollow shaft, inner diameter	8.5 mm
Hollow shaft (push-through - when stopped)	yes
Fastening on stand	extension arm
Extension arm diameter	13 mm
Extension arm length	160 mm
Nominal torque	0.2 Nm
Timer display	none
Housing material	alu-cast coating / thermoplastic polymer
Dimensions (W x H x D)	70 x 193 x 147 mm
Weight	1.56 kg
Permissible ambient temperature	5 - 40 °C
Permissible relative humidity	80 %
Protection class according to DIN EN 60529	IP 54
USB interface	Micro-USB
Voltage	100 - 240 V
Frequency	50/60 Hz
Power input	69 W
Power input standby	0.5 W
DC Voltage	24 V=
Current consumption	2900 mA
