Hydro-Bios RHCM Rod Held Current Meter Portable Flow Velocity Indicator

Hydro-Bios RHCM [445 515] Rod Held Current Meter Portable Flow Velocity Indicator

This portable device is a point-by-point measuring instrument for assessing the current speeds in running waters. The RHCM consists of a hydrometric three-blade impeller at the lower end of a telescopic rod and a splash-proof Hand Terminal. The measuring head can be angled up to ±90°. The measuring values are displayed together with a date and time stamp on a hand terminal. They can be stored and transferred to a PC by means of the software OceanLab 3. At the PC the measuring files are stored in ASCII format for processing with current word processing, spread sheet and database software.

Features:

• Data memory up to 4 MByte
• Mains supply circuit
• Submerging depth of the measuring head up to 100 meters using
• a cable (without Telescopic Rod).
• Measuring range 0.100 ... 9.999 m/s
• Resolution 0.001 m/s
• Accuracy ±1 % (0.50 ... 9.99 m/s)
• ±5 % (0.10 ... 0.499 m/s)
• Measuring cycle 5 to 30 s (user adjustable)
• Memory 4000 measuring values
• Ambient temperature 0°C ... 50°C
• Submerging depth of measuring head 10 m
• Hand Terminal splash-proof IP 65
• EC-Conformity (CE) EN 50081-1, EN 50082-1
• Power supply Battery 9 V (PP3)
• or external: 7...12 V, max.12 mA

What's In The Box:

• (1) Rod Held Current Meter RHCM
• (1) HydroLink® Software
• (1) Telescopic rod 3 x 150 cm (450 cm)
