SAUERMANN Si-CA 030 Combustion Gas Analyzer Model SICA 030 KIT 2AS REF. No. 27496

SAUERMANN Si-CA 030 Combustion Gas Analyzer Model SICA 030 KIT 2AS REF. No. 27496

Si-CA 030 Gas Analyzer Kit 2AS, includes two gas sensors (O2, CO), upgradable to three gas sensors (NO/NOx), 180 mm probe rated to 800 °C with 2 m dual hose, wireless connection to mobile app and remote printer (option), rubber holster, water trap with filter, charger with plug set, USB-C cable, quick start guide, calibration certificate and vinyl carrying bag

Up to three gas sensors O2, CO and NO (for NOx)

CO sensor measurement up to 8,000 ppm

Auto pump cut-off for high CO levels

Color display screen

Lightweight, only 350 g (12 oz)

Data management with automatic logging & report creation

MEASURE DETAILS

Units : inH2O, °F, °C, %, ppm, mbar

MEASURING RANGES

O2 : 0.00 % ... 25.00 %

CO : 0.00 ppm ... 8000.00 ppm

CO2 : 0.00 % ... 99.90 %

Flue temperature : -20.00 °C ... 1250.00 °C

Air temperature : -20.00 °C ... 120.00 °C

Differential temperature : 0.00 °C ... 1250.00 °C

Pressure/Draft : -200.00 mbar ... 200.00 mbar

Excess air : 0.00 % ... 999.00 %

Efficiency : 0.00 % ... 100.00 %

Efficiency (condensation) : 0.00 % ... 125.00 %

TECHNICAL DETAILS

Parameters : Gas analysis

Displays : Color graphical display

IP Protection : IP 42

Battery life : 8 hours

Standards : 2015/863 EU (RoHS 3), NF EN 50379-1, NF EN 50379-2, 2014/53/EU RED

Wireless connection : 1

Power supply : Rechargeable battery, Li-Ion 5100 mA/h 3.6 V

Usb : Yes

Sensors : CO, O2

Auto zero : Yes

Printer : Remote

Sensor protection : Sensor protection by pump stopping

Combustion condensate

Remote

Mobile application : Yes

INSTRUMENT DIMENSIONS

Length : 99 mm

Width : 49 mm

Height : 194 mm

Weight : 350 g

OPERATING TEMPERATURE

Min : -5.00 °C

Max : 45.00 °C

STORAGE TEMPERATURE

Min : -20.00 °C

Max : 50.00 °C
