Hitachi V series hoist with motorized trolley 10 tons

Jual Hitachi V-series Hoist Crane with motorized trolley 10 tons

Distributor Hitachi V-series Hoist Crane with motorized trolley 10 tons

Standard Specifications
Electric Source    3-Phase 200V 50/60Hz, 220V 60Hz,
380V to 400V/415V 50Hz, 400 to 440V 60Hz
Operation Method    Operating push button
Power Feeding Method and Push Button
Type    Power Feeding System    No. of push buttons    Indication
Suspension type, manual or chain driven trolley    Cable    2    push buttonpush button
With motorized trolley    With motorized trolley up
to 5 to except 5 ton
double rail type    Cable feeding    6    push buttonpush button
push buttonpush buttonpush buttonpush button
With motorized trolley
of 7.5 ton and up include 5 ton
double rail type    8    on offpush buttonpush button
push buttonpush buttonpush buttonpush button
No cable included with standard shipment.

Rating    30 minutes (to JIS C9620, Japanese Industrial Standard)
Max. No. of starts per hour

Light    Load less than half the rating, and the rated load seldom applied    K≤0.5    star    star    star    star    star    circle
Medium    Almost the same ratio of small, medium, and full loads    0.5<K≤0.63    star    star    star    star    circle    circle
Heavy    Load near to the rated one    0.63<K≤0.8    star    star    star    circle    circle    circle
starDuty factor: 40% (40%), Max. No. of starts per hour: 400/h (250/h)
circleDuty factor: 40% (25%), Max. No. of starts per hour: 250/h (250/h)

Capasitas: 10 tons

*1Value between the parentheses is for 15 ton and up
Color (Munsell color)    Munsell 2.5B2.5/1
Electrical Protection    IP44
Ambient Temperature    -10～40°C
Humidity Range    90% or less (No condensation)
Approval    JIS C9620, Japanese Industrial Standard
