OmniScan SX Portable Flow Detector Olympus

Specifications

The basic instrumentation and software criteria outlined in ASME, AWS, API, and EN regulations are met or exceeded by the OmniScan SX.

Source: Evident Corporation

.
Housing	Overall dimensions (W x H x D)	267 mm × 208 mm × 94 mm (10.5 in. × 8.2 in. × 3.7 in.)
	Weight	3.4 kg (7.5 lb) with battery
Data Storage	Storage devices	SDHC card* or most standard USB storage devices. *Lexar® brand memory cards are recommended for optimized results.
	Data file size	300 MB
I/O Ports	USB ports	2 USB ports, compliant with USB 2.0 specifications
	Audio alarm	Yes
	Video output	Video out (SVGA)
I/O Lines	Encoder	2-axis encoder line (quadrature, up, down, or clock/direction)
	Digital input	4 digital TTL inputs, 5 V
	Digital output	3 digital outputs TTL, 5 V, 15 mA maximum per output
	Acquisition on/off switch	Yes, through configuration of a digital input
	Power output line	5 V, 500 mA power output line (short-circuit protected)
	Pace input	5 V TTL pace input
Display	Display size	21.3 cm (8.4 in.) (diagonal)
	Resolution	800 pixels x 600 pixels
	Brightness	600 cd/m2
	Viewing angles	Horizontal: –80° to 80° Vertical: –60° to 80°
	Number of colors	16 million
	Type	TFT LCD
Power Supply	Battery type	Smart Li-ion battery
	Number of batteries	1
	Battery life	Minimum 6 hours under normal operating conditions
Environmental Specifications	Operating temperature range	-10 °C to 45 °C (14 ºF to 113 ºF)
	Storage temperature range	–20 °C to 60 °C (–4 ºF to 140 ºF) with battery –20 °C to 70 °C (–4 ºF to 158 ºF) without battery
	Relative humidity	Max. 70% RH at 45°C noncondensing
	Ingress protection rating	Designed to meet requirements of IP66
	Shockproof rating	Drop-tested according to MIL-STD-810G 516.6
Ultrasound Specifications (applies to OMNISX-1664PR)	Connectors	1 Phased Array connector: Olympus PA connector 2 UT connectors: LEMO 00
	Number of focal laws	256
	Probe recognition	Automatic probe recognition
Pulser/Receiver	Aperture	16 elements
	Number of elements	64 elements
	Pulser	PA Channels	UT Channel
	Voltage	40 V, 80 V, and 115 V	95 V, 175 V, and 340 V
	Pulse width	Adjustable from 30 ns to 500 ns; resolution of 2.5 ns	Adjustable from 30 ns to 1,000 ns; resolution of 2.5 ns
	Pulse shape	Negative square wave	Negative square wave
	Output impedance	35 Ω (pulse-echo mode); 30 Ω (pitch- catch mode)	<30 Ω
	Receiver	PA Channels	UT Channel
