ADDITEL ADT220 Multifunction Loop Calibrator

Features:
Measuring and sourcing loop current, mV and V: Measures loop current up to 30mA with 0.1μA resolution. Measures voltage signals up to 60 V, and mV signals up to 300 mV. Sources/sink loop current, mV and V. 24V loop power supply with simultaneous current measurement. Simultaneous dual reading capability. Capture switch.
Data statistics and analysis: Display max, min, peak-to-peak, average, and percentage simultaneously. Convert data to a real physical value through re-scaling function.
Data logging: High-capacity storage with up to twenty thousand records. On-line view, index, analyze, auto-curve, and list the data.
Various sources and converting mode: Support linear, flow, valve, and 25% stepping source. Auto-source of ramping and stepping Gauge span examination.
"As Cal" on-site calibration tools: Four on-site calibration tools preset: loop indicator, sensor/transmitter, signal isolator/converter, and limit alarm/switch.
Support 2W transmitter connection
Multi lingual interface: English,Simplified Chinese.
Convenient tools: Calculator, thermocouple converter, HOLD screen lock
Easy to use: Smartphone-like menu and interface make the operation simpler and easier. Ultra-compact, size 3.9" x 7.6" x 2.0" (100mm x192mm x 52mm), and weight 1.6 lb (0.7 kg). One hand operation.
Snapshot: Save and manage up to 100 snapshots.
Display: 3.5 inch TFT color screen. 4, 5, or 6 digits adjustable display.
Rugged: Rugged design for harsh environments. Passed a 1-meter drop test. Three years warranty for the 220, and one year for the battery pack.
Misuse protection and Electrical isolation: Up to 30V voltage on any two sockets and up to 1A current on current sockets will not damage the calibrator. The calibrator will return to normal condition as soon as the voltage or current is removed. Measuring, sourcing and loop power circuits are electrically isolated each other.
Rechargeable battery: Rechargeable Li-ion battery for 15 hours uninterrupted use. Battery life will be reduced when 24V is applied. The rechargeable battery is replaceable.
NIST Traceable Calibration with data.
Firmware upgrade: Support firmware upgrade when available.
Warranty: 3 years

The Additel ADT220 Multifunction Loop Calibrator is a highly integrated loop calibrator featuring several patented technologies, the calibrator is an ultra-compact, rugged, and best of all, easy to use hand-held device that will source, simulate and measure loop current, mV/V, loop integrity, and also perform switch testing. Its smart phone-like menu and interface makes it simple and easy to use. The Additel ADT220 is ideal for calibrating, maintaining, and troubleshooting various loop devices in the field.

The Additel ADT 220 loop calibrator is a process tool for measuring, sourcing and simulating mA, mV and V, captures switch values and provides 24 V loop power. The Additel ADT220 is a high performance solution for calibration, repair and maintenance of various loops devices, loop integrity check, and switch capture.

Includes:
110V/220V external power adapter
Chargeable Li-ion battery
Test leads
Short Circuit Cable
NIST traceable calibration certificate
Instruction Manual
