Total Station Sokkia Cxseries 103 105

Cv.Gihon Juma Sentosa Adalah Distributor Total Station Sokkia Cxseries 103 105
Total Station

¬ Advanced Angle Measurement System
Absolute Encoders Sokkia Original • Cx Features That Provide Long-Term Reliability In Any Conditions Of Work Sites . Dual - Axis Compensator Ensures Stable Measurement Even When The Setup On Uneven Terrain .
• Sokkia Traditional Motion Clamp And Tangent Screws Are Employed To Ensure A Stable Angle Measurement .
• Cx101 And Cx102 Innovative Features Iacs ( Independent Angle Calibration System ) Technology For Extremely Reliable Angle Measurement .

The Longest Battery Life - 36 Hours !
• The Cx Single Battery Can Last Up To 36 Hours . * 2
• It Reduces The Possibility Of Low Power During Each Full Working Day .
• Eliminates The Need For A Night Or An Extra Battery Recharging .
* 1 In December 2011 .
* 2 Operating Time Will Vary Depending On Environmental Conditions And The Activity Of Cx .

Waterproof , Rugged , And Operator Friendly
• Rating Ip66 Dustproof / Waterproof .
• Metal Chassis And Heavy Duty Handles Add Roughness .
• Temperature Range Of 20 ° Standard Usage To +50 ° C. The Low Temperature Model Can Be Used As Low As -30 °
And Models Of High Temperature Up To +60 ° C.
• Usb Port For Convenient Typea Added Memory . Use Of Accessories Including Usb Ensures Protection Ip66 .
• One - Touch Button Of [ ? ] Offers Quick Access To Functions .
• Based " Trigger " Key Lets You Take A Series Of Measurements With The Push Of A Button Without Taking Your Eye From The Telescope .
• The Control Panel Features A Large 10 - Key Pad With Lcd Display And Provide Optimal Comfort .
• Green / Red Light Telescope Guide To Improve Efficiency In The Range Of Up To 150M .
• Built - In Laser Plummet With Five Levels Of Brightness Equipped Instrument For Setting Fast In All Lighting Conditions .
Cx Specifications
Models ; Cx 101 Cx102 Cx103 Cx105
Telescope ;
Magnifications ; 30X / 2-5 "
Display Resulotion ; 0.5 " / 1 " 1 " / 5 "
Acuration ; 1 " 2 " 3 " 5 "
Internal Data Memory Of 500 Mb
        Plug In A Usb Memory Flash Memory [ Max 8 Gb ]
Control Panel Location On Both Faces [ Face 2 Is Only Tooch Screen Display ]
Aesuring Reflectoriess Range 0.3 To 500Mtr [ 1,0 To1 , 640Ft
Reflectipe Shert
Mini Prism To 2,500 M ---- 500M
One Ap Prism To 4000M ---- 5,000 M
Tree Ap Prism To 5000M [ 16,400 Ft ] -Under Good Condition ; To 6.000 [ 19.680 Ft ]
