TROTEC Type BE50 Digital Multi-Meter

Multimeter

TROTEC Type BE50 Digital Multi-Meter

With altogether eleven measuring functions, automatic range selection, temperature measurement with type K contact sensor, hold function and display illumination this measuring device is suited for manifold fields of application in the industrial or semi-professional sector.

The fully equipped, practice-oriented BE50 with IP67 type of protection impresses with excellent quality finish and robustness:

Measuring device and measuring lines are doubly insulated and conform to protection class II. Moreover, this digital multimeter is extremely impact-, dust- and water-proof – and thus optimally suited for tough everyday usage!

Technical data of the BE50:

• Display: LCD with four-figure display
• Measuring range (accuracy) of the voltage: 0.1 mV to 1000 V (UDC ± 1.2 %, UAC ± 2 %)
• Measuring range (accuracy) of the electricity: 100 nA to 10 A (DC ± 1.5 %, AC ± 2.5 %)
• Measuring range (accuracy) of the capacity: 10 pF to 100 µF (± 3 %)
• Measuring range (accuracy) of the resistance: 0.1 Ω to 10 MΩ (± 1.2 %)
• Measuring range (accuracy) of the frequency: 1 mHz to 10 MHz (± 1.2 %)
• Measuring range (accuracy) of the temperature: -20 °C to +760 °C (± 3 %)
• Measuring range (accuracy) of the duty cycle: 0.1 % to 99.9 % (± 1.2 %)
• Functions : For measuring voltage, electricity, resistance, frequency, contact temperature, duty cycle; flow test, diode test, automatic range selection, hold function, illuminated display, automatic battery test, auto power off
• Measuring circuit category: CAT III 1000 V / CAT IV 600 V
• Safety: EN 61326, EN 61010-1, EN 61010-02-031
• Insulation: Protection Class II
• Type of protection: IP67
• Weight: 320 g
• Scope of supply: Meter, a pair of measuring leads, Type K contact sensor, battery, operating instructions
