Hantek DSO1060 Handheld Oscilloscope

Hantek DSO1060 Handheld Oscilloscope

This lightweight, durable "scope-meter" acts as both a two channel digital 60 MHz oscilloscope, and a 6000 count digital multimeter. It comes complete with oscilloscope probes and multimeter probes. The oscilloscope functions are intuitive and familiar to work with, and setup is quick and easy. The multimeter has Voltage, Current, Resistance, and Capacitance ranges, and it also checks diodes and continuity. This oscilloscope comes with a 3500 mAH lithium ion battery and a one year factory warranty. Delivered with latest factory firmware. Current version is 1.77.

The DSO-1060 can be attached to your PC via USB with the included free software. It also comes with a carrying case and shoulder strap, the two types of probes, the AC power adapter, USB cable, operator's manual, and the software CD.

* 60MHz bandwidth
* 250MSa/S real time sampling rate
* 50GSa/S equivalent sampling rate
* Capable of 22 different waveform measurements
* Alternative (ALT) Trigger mode allows for triggering on 2 non-related signals
* 6000 count DMM resolution with AC/DC at 600V/800V, 10A
* Large 5.7 inch TFT color LCD display
* USB 2.0 connectivity
    • Attach to a computer for larger screen displays
    • Data storage via computer interface (jpg/bmp or MS Excel/Word files)
    • Free Software with SDK for User Development in Labview, Visual Basic, Visual C
* Multi-language support
* 6 hour Li-ion battery
