Flexo Flat Cable H07VVH6 For Hoist Crane

Buka setiap hari termasuk hari minggu/libur, silahkan di pesan barang nya dan kami akan mengirimkan barang pesanan anda secepat mungkin.

Flexo Flat Cable H07VVH6-F, Made in Italy

• Conductors nominal cross section (n. x mm²) : 4x1,5mm²

• Approx. Outer dimensions of cable (Height x width) : 5,1 x 14,5

• Copper Weight (kg/km) : 58

• Approx. Cable weight (kg/km) : 135

Technical Data :

• Conductor Resistance : According to VDE 0295 Class 5 and IEC at 20?C

228 Class 5 for flexible conductors

• Temperature at the conductor max : +70?C in operation + 150?C

in the event of a short circuit.

• Insulation resistance at 20?C min : 20 MW·km

• Rated Voltage : H07VVH6 U0 /U : 450 / 750 V

• Test Volteage AC, 50Hz : H07VVH6 : 3000 V

Temperature Range :

• Mobile : -5?C to + 70?C

• Fixed : -40?C + + 70?C

• Radiation resistance : 80 Mrad (80 x 106 cJ/kg)

• PVC characteristics : self-extinguishing and flame-retardant

• Breakdown voltage min : 6000 V

• Bending Radius : 10 x cable thickness

Testing according to DIN VDE 0472 and IEC regulation

• Flame Test : test class B according to VDE 0472 part 804, IEC 332-1

Features

+ The reduced dimension means that these flat flexible cables

+ are space saving compared to round flexible cables.

+ The Cables must be rolled up and suspenden such that no twisting.

+ The Cable should be freely suspended, secured at one end,

+ in the lift shaft for several days before being installed.

+ Chemical resistance properties of PVC-refer also to

+ the Tbale of Technical Guidelines.
