WOODWARD 8440-2166 SPM-D2-10 SYNCHRONIZER SPMD2 84402166 SPM D2 8440 2166

WOODWARD 8440-2166 SPM-D2-10 Synchronizer

8440-2166
SPM-D2-1010B
Synchronizer 100 Vac

The SPM-D2-10 series are microprocessor-based synchronizers designed for use on three phase AC generators equipped with Woodward or other compatible speed controls and automatic voltage regulators. The SPM-D2-10 synchronizers provide automatic frequency, phase and voltage matching using either analog or discrete output bias signals. These synchronizers are applied to a wide range of prime movers and generators, as their control signals may be set to fit several types of gensets -- from fast-reacting diesel engines to soft-reacting gas turbines.

FEATURES & FUNCTIONALITY
We understand the time-intensive nature of power generation projects and ensuring the longevity of components is a specific way we contribute to our customers’ success. We’ve supplied and supported the well-established SPM-D line of synchronizers for over 20 years. And, now, the new SPM-D2 with its state-of-the-art technology extends the life of your synchronizers as a drop in replacement for your SPM-D units.

The SPM-D2-10 series are microprocessor-based synchronizers designed for use on three phase AC generators equipped with Woodward or other compatible speed controls and automatic voltage regulators. The SPM-D2-10 synchronizers provide automatic frequency, phase and voltage matching using either analog or discrete output bias signals. The SPM-D2-10 provides 1-phase / 2-wire voltage measurement with options for analog or discrete biasing signals and wide range power supply.  These synchronizers are applied to a wide range of prime movers and generators, as their control signals may be set to fit several types of gensets -- from fast-reacting diesel engines to soft-reacting gas turbines.

All SPM-D2 synchronizers are password protected and configurable either through HMI (as were the SPM-D units) or through the ToolKit configuration tool with USB connectivity.

Benefits include:
Compatible with a wide range of governors, automatic voltage regulators, and circuit breakers
True RMS voltage sensing for reduced susceptibility to harmonics
Front face synchroscope for easy commissioning
HMI programming and USB connectivity to Woodward ToolKit service tool
Drop-in replacement for existing SPM-D10 synchronizers
