AEMC AC Current Probe Model MD301 aemc

AEMC AC Current Probe Model MD301 aemc

Spesifikasi

Model: AEMC MD301

Nomor katalog: 1201.07

Jenis: AC Current Probe / Clamp Current Probe

Jenis pengukuran: Arus AC

Rentang arus nominal: 500 A AC

Rentang pengukuran: 2–500 A AC

Rasio transformasi: 1000:1

Sinyal output: 1 mV DC/A AC

Output maksimum: 0,5 V DC pada 500 A AC

Konektor output: Kabel 1,5 m dengan 2 safety banana plug 4 mm

Jarak antar banana plug: 19 mm (¾")

Diameter kabel maksimum: 30 mm

Ukuran busbar maksimum: 63 × 5 mm

Diameter dual cable maksimum: 25 mm

Akurasi: 5% @ 25 A; 2% @ 100 A; 1% @ 250 A; 1% @ 500 A

Rentang frekuensi: 48 Hz–1 kHz

Impedansi beban: ≥100 kΩ

Overload: 700 A selama 10 menit

Tegangan kerja: 600 V RMS

Tegangan common mode: 600 V RMS

Kategori keselamatan: 600 V CAT III / 300 V CAT IV

Ingress Protection: IP20

Pollution Degree: 2

Suhu operasi: −15°C hingga +50°C

Suhu penyimpanan: −40°C hingga +85°C

Dimensi: 66 × 195 × 34 mm

Berat: ±420 g

Material rating: UL 94 V0

Standar EMC: EN 50081-1 Class B, EN 50082-2, IEC 61000-4-2

Standar keselamatan: EN 61010-2-32

Aplikasi: Recorder, data logger, dan instrumen dengan input mV DC.

AEMC AC Current Probe Model MD301 aemc

Specifications

Model: AEMC MD301

Catalog Number: 1201.07

Type: AC Current Probe / Clamp Current Probe

Measurement Type: AC Current

Nominal Current Range: 500 A AC

Measurement Range: 2–500 A AC

Transformation Ratio: 1000:1

Output Signal: 1 mV DC/A AC

Maximum Output: 0.5 V DC at 500 A AC

Output Connection: 1.5 m lead with two 4 mm safety banana plugs

Banana Plug Spacing: 19 mm (¾")

Maximum Cable Diameter: 30 mm

Maximum Busbar Size: 63 × 5 mm

Maximum Dual Cable Diameter: 25 mm

Accuracy: 5% @ 25 A; 2% @ 100 A; 1% @ 250 A; 1% @ 500 A

Frequency Range: 48 Hz–1 kHz

Load Impedance: ≥100 kΩ

Overload: 700 A for 10 minutes

Working Voltage: 600 V RMS

Common Mode Voltage: 600 V RMS

Safety Rating: 600 V CAT III / 300 V CAT IV

Ingress Protection: IP20

Pollution Degree: 2

Operating Temperature: −15°C to +50°C

Storage Temperature: −40°C to +85°C

Dimensions: 66 × 195 × 34 mm

Weight: Approx. 420 g

Material Rating: UL 94 V0

EMC Standard: EN 50081-1 Class B, EN 50082-2, IEC 61000-4-2

Safety Standard: EN 61010-2-32

Applications: Recorders, data loggers, and instruments with mV DC inputs.
