AEMC AC Current Probe Model MN01 aemc

AEMC AC Current Probe Model MN01 aemc

Spesifikasi

Model: AEMC MN01

Nomor katalog: 2129.17

Jenis: AC Current Probe / Clamp Current Probe

Jenis pengukuran: Arus AC

Arus nominal: 150 A AC RMS

Rentang pengukuran: 2–150 A AC

Rasio transformasi: 1000:1

Sinyal output: 1 mA/A AC

Output pada 150 A: 150 mA AC

Konektor output: Kabel 1,5 m dengan safety banana plug 4 mm

Ukuran konduktor maksimum: Ø10 mm

Rentang frekuensi: 48–500 Hz

Akurasi dengan beban 1 Ω: ≤2,5% pembacaan ±0,15 A

Akurasi dengan beban 10 Ω: ≤3% pembacaan ±0,15 A

Phase Shift: Tidak ditentukan

Impedansi beban: Maks. 10 Ω

Tegangan sekunder terbuka: ≤30 V

Overload: 170 A selama 10 menit ON / 30 menit OFF

Tegangan kerja: 600 V RMS

Tegangan common mode: 600 V RMS

Pengaruh konduktor berdekatan: <2 mA/A pada 50 Hz

Pengaruh posisi konduktor: <0,1% output mA pada 50/60 Hz

Pengaruh frekuensi: <2% output mA pada 65–500 Hz

Dimensi: 112,5 × 37,5 × 26 mm

Berat: ±180 g

Suhu operasi: −10°C hingga +50°C

Suhu penyimpanan: −40°C hingga +80°C

Kelembapan operasi: 10–90% RH

Ingress Protection: IP40

Kategori keselamatan: 600 V CAT III / 300 V CAT IV

Pollution Degree: 2

Double Insulation: Ya

Standar EMC: EN 61326-1

Aplikasi: DMM/multimeter, data logger, recorder, oscilloscope, panel breaker, HVAC, dan aplikasi industri.

AEMC AC Current Probe Model MN01 aemc

Specifications

Model: AEMC MN01

Catalog Number: 2129.17

Type: AC Current Probe / Clamp Current Probe

Measurement Type: AC Current

Nominal Current: 150 A AC RMS

Measurement Range: 2–150 A AC

Transformation Ratio: 1000:1

Output Signal: 1 mA/A AC

Output at 150 A: 150 mA AC

Output Connection: 1.5 m lead with 4 mm safety banana plug

Maximum Conductor Size: Ø10 mm

Frequency Range: 48–500 Hz

Accuracy with 1 Ω Load: ≤2.5% of reading ±0.15 A

Accuracy with 10 Ω Load: ≤3% of reading ±0.15 A

Phase Shift: Not specified

Load Impedance: 10 Ω maximum

Open Secondary Voltage: ≤30 V

Overload: 170 A for 10 minutes ON / 30 minutes OFF

Working Voltage: 600 V RMS

Common Mode Voltage: 600 V RMS

Adjacent Conductor Influence: <2 mA/A at 50 Hz

Conductor Position Influence: <0.1% of mA output at 50/60 Hz

Frequency Influence: <2% of mA output from 65–500 Hz

Dimensions: 112.5 × 37.5 × 26 mm

Weight: Approx. 180 g

Operating Temperature: −10°C to +50°C

Storage Temperature: −40°C to +80°C

Operating Humidity: 10–90% RH

Ingress Protection: IP40

Safety Rating: 600 V CAT III / 300 V CAT IV

Pollution Degree: 2

Double Insulation: Yes

EMC Standard: EN 61326-1

Applications: DMMs/multimeters, data loggers, recorders, oscilloscopes, breaker panels, HVAC, and industrial applications.
