Function signal generator Aditeg AFG 8125

Cv.Gihon Juma Sentosa Adalah Distributor Function signal generator Aditeg AFG 8125
The instrument is an accurate testing instrument.

It can output the function wave: sine wave, square wave, rectangle wave, sawtooth

wave and triangle wave.

The frequency, amplitude and duty cycle can be adjusted continuously.

Frequency range: 0.2-2MHz

5-digit LED frequency display, 3-digit LED amplitude display synchronously.

Attenuation: 20dB/40dB

Specification

Frequency range 0.2Hz/2Hz/20Hz/200Hz/2kHz/20kHz/200kHz /2MHz

Amplitude (2Vp-p~20Vp-p) 20%

Output signal impedance 50

Attenuation 20dB/40dB

Duty cycle 20%~80% (10%)

Displaying 5 digits LED frequency display and 3 digits LED amplitude display synchronously

Sine wave Distortion 2%

Triangle wave Linearity 99%

Square wave Rise edge tines /fall edge times 100nS

Time base Symmetry frequency: 12MHz, frequency stability: 510-5

Signal frequency stability 0.1%/Minute

Measurement error 0.5%

Dimension 270 mm215 mm100mm

Weight Approx: 3 kg

Power 220V

Accessories :

- Power Cord

- BNC to BNC Cable

- BNC to Alligator Clips Cable

- Instruction manual

Made in China
