AEMC AC Current Probe Model JM861 aemc

AEMC AC Current Probe Model JM861 aemc

Spesifikasi

Model: AEMC JM861

Nomor katalog: 2110.90

Jenis: AC Current Probe

Jenis pengukuran: Arus AC

Rentang arus: 30 A / 300 A / 3.000 A AC

Rentang pengukuran: 1–30 A / 1–300 A / 1–2.400 A AC

Maksimum arus: 3.000 A AC pada suhu <35°C

Output 30 A: 10 mV/A AC

Output 300 A: 1 mV/A AC

Output 3.000 A: 0,1 mV/A AC

Output maksimum: 0,3 V pada masing-masing range

Konektor output: BNC terisolasi

Panjang kabel: ±2 m (6,5 ft)

Rating konektor: 600 V RMS

Rentang frekuensi: 10 Hz – 50 kHz

Derating arus: Diperlukan di atas 5 kHz untuk penggunaan kontinu

Akurasi range 30 A: 2% ±1 mV

Akurasi range 300 A: 2% ±0,5 mV

Akurasi range 3.000 A: 2% ±0,2 mV

Phase shift: 5° @ 30 A / 1° @ 300 A / 1° @ 3.000 A

Impedansi beban: 1 MΩ, 47 pF

Tegangan kerja/common mode: 600 V AC

Diameter kabel maksimum: 64 mm

Ukuran busbar maksimum: 50 × 135 mm atau 64 × 100 mm

Dimensi: 120 × 315 × 48 mm

Berat: ±1,2 kg

Suhu operasi: −10°C hingga +50°C

Suhu penyimpanan: −40°C hingga +80°C

Ingress Protection: IP20

Double insulation: Ya

Aplikasi: Oscilloscope, waveform analyzer, electrical utility, HVAC, industrial maintenance, laboratory, dan plant maintenance.

AEMC AC Current Probe Model JM861 aemc

Specifications

Model: AEMC JM861

Catalog Number: 2110.90

Type: AC Current Probe

Measurement Type: AC Current

Current Range: 30 A / 300 A / 3,000 A AC

Measurement Range: 1–30 A / 1–300 A / 1–2,400 A AC

Maximum Current: 3,000 A AC at temperatures below 35°C

Output at 30 A: 10 mV/A AC

Output at 300 A: 1 mV/A AC

Output at 3,000 A: 0.1 mV/A AC

Maximum Output: 0.3 V on each range

Output Connector: Insulated BNC

Cable Length: Approx. 2 m (6.5 ft)

Connector Rating: 600 V RMS

Frequency Range: 10 Hz – 50 kHz

Current Derating: Required above 5 kHz for continuous use

Accuracy – 30 A Range: 2% ±1 mV

Accuracy – 300 A Range: 2% ±0.5 mV

Accuracy – 3,000 A Range: 2% ±0.2 mV

Phase Shift: 5° @ 30 A / 1° @ 300 A / 1° @ 3,000 A

Load Impedance: 1 MΩ, 47 pF

Working/Common Mode Voltage: 600 V AC

Maximum Cable Diameter: 64 mm

Maximum Busbar Size: 50 × 135 mm or 64 × 100 mm

Dimensions: 120 × 315 × 48 mm

Weight: Approx. 1.2 kg

Operating Temperature: −10°C to +50°C

Storage Temperature: −40°C to +80°C

Ingress Protection: IP20

Double Insulation: Yes

Applications: Oscilloscopes, waveform analyzers, electrical utilities, HVAC, industrial maintenance, laboratories, and plant maintenance.
