Digital Signage (Digital Large Interactive Display) DT-I55HT

INPUT

LAN IN : 1

AV IN : 1

HDMI 2.0 : 2

RS-232 : 1

USB 3.0 : 1

USB 2.0 : 1

TF-CARD : 1

OUT

AV OUT : 1

Earphone : 1

Coaxial (RCA) : 1

TOUCH OUT : 1

FRONT PORT AND FUNCTION

USB3.0 : 3

HDMI 2.0 : 1

USB TOUCH : 1

Type-C Full Function : 1

Recovery System : 1

Front Button :

ANDROID SPECS

Android Frequency : Quad core ARM Cortex-A55

System Version : Android 11

DDR4 RAM : 4G

FLASH Memory : 32G

WIFI : 2.4G/5G

OTHERS

Power consumption of the whole machine (excluding OPS) : ≤120W

Standby Consumption : ≤0.5W

Lifetime : 50000 hours

Power Supply : 100-240V, 50/60Hz

Demission : 1267.8*789.9*93.44mm

VESA Hole Site : 4-M8 hole site 400mm*400mm

Net Weight : 28kg

Gross Weight : 32.4kg

TOUCH SCREEN

Touch Technology : Multiple Infrared scanning technology

Touch Type : 40 point touch

Drive Mode : HID Free drive

Writing Surface Material : 3mm anti glare tempered glass

Touch Screen Sensor Mode : Finger, writing pen, hand with gloves or other non transparent touch sensitive medium

Resolution of Touh Screen : 32768X32768

Communication Port : USB 2.0

Minimum Recognition Point Size : 2.5mm

Response TimSez(SingleTouch) : ≤5ms

Touch Accuracy : ±1mm

Anti-Interference : Incandescent lamp (220V, 100W), vertical distance 350mm above, The illumination intensity of the sun is up to 80000Lux

Calibration : Calibration free

Touch Time : More than 60 million times in the same position

ACCESSORIES

Wall-Mount : 1pcs

Pen : 1pcs

Power Cable : 1pcs

PC (Optional)

PC Option : H81/H110/H310 Mainboard

Input Voluge : 18V DC

Rated Output Current : 5A

Peak Output Current : 6A

Rated Load Power : 90W

Interface : Canform  to Intel®  OPS-C JAE 80-pin connector

National Standard OPS Size : L194.6*W179.8*H42mm（42mm or 30mm）
